MIXER
ISOLATOR
POWER
CONTROL
120v/240v PSU
14lb : 4.5kg
10lb : 6.4kg
9.6lb : 4.35kg
6.8lb : 3.08kg
3.2lb : 1.45kg
WIDTH : 19" - 483mm
WIDTH : 7" - 177mm
DEPTH : 8" - 203mm
DEPTH : 5" - 127mm
3U
2U
1U
HEIGHT : 2.75" - 69.85mm
PHONO
LINE
Phono IN through trim, pan to house OUT
single ended mode
10mV RMS, 40dB phono stage gain
Line IN through trim, pan, to house OUT
single ended mode
2V RMS input, unity gain
THD, %
0.004
0.0005
THD+N,%
0.020
0.0010
SNR, dB
74
101
